ANSMANN TC230PD USB Interchangeable Travel Charger

This travel charger is a practical charging device for USB-enabled gadgets. It has two ports: a USB-A and a USB-C, delivering up to 30W with Power Delivery (PD) fast-charging technology.

Suitable for worldwide use with a 100-240V input voltage, it's also travel-friendly with a foldable connector and attachable EU and UK plugs. Safety features include protection against overvoltage, short circuits, and overheating.

This charger is a great solution for charging needs at home or while travelling.

Features

• For ultra-fast charging of all USB-capable devices
• Power Delivery (PD) fast charging up to 30W
• Integrated, foldable US connector
• Multi-safe technology protects against overvoltage, short circuit and overheating
• Input voltage: 100-240V, for worldwide use

Specifications

Input Plug	Extendable US plug and attachable EU and UK plugs
Input current	Max. 1.0 A
Input Voltage	100 V - 240 V ± 10 % AC
Input AC Frequency	50 Hz / 60 Hz
Average Active Efficiency	≥ 80.39 %
Efficiency at Low Load (10%)	78.00%
No-load Power Consumption	≤ 0.30 W
Protection Class	II
Housing Material	PC
Housing Type	Plug-in case
Ambient Temperature at Operation	-20 ° C ~ 25 ° C
Storage Temperature	-25 ° C ~ 75 ° C
Approvals	CE
Net Weight (Approx.)	Power supply: 102 g EU plug: 14.2 g UK plug: 19.2 g
Output Protection Functions	Short Circuit Overvoltage Over Current
Insulation (Primary/Secondary)	3 kV

Resources

• Datasheet
• User Manual

Package Contents

• 1x TC230PC USB Interchangeable Travel Charger
• 1x Attachable EU plug
• 1x Attachable UK plug
