16mm Panel Mount Momentary Pushbutton - Burgundy
These small 16mm panel mount buttons are great for custom arcade projects or even just as a simple button as an input. These are the momentary type - they're off until you push the button, but they won't latch and stay on - ideal for gaming inputs.
The rear terminals work perfectly with ourĀ 2.8mm/0.11" quick-connect wires, which press on firmly for a solid connection.
This is theĀ BurgundyĀ version -Ā we sell many more colours in the store. Each button comes with a split ring washer and nut to secure to your panel or enclosure.
Remember to useĀ resistorsĀ if using this as an input forĀ microcontrollerĀ or you'll be slathered in the magic blue smoke!
Specifications
- Max Dimensions: 18.06mm / 0.7" x 18mm / 0.7" x 29.4mm / 1.15"
- Shaft Dimensions: 14.89mm / 0.58" x 15.56mm / 0.6" x 18.7mm / 0.73"
- Button Height: 5mm
- Button Height Depressed: 3.5mm
- Weight: 4.6g
Original: $2.04
-70%$2.04
$0.61Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
These small 16mm panel mount buttons are great for custom arcade projects or even just as a simple button as an input. These are the momentary type - they're off until you push the button, but they won't latch and stay on - ideal for gaming inputs.
The rear terminals work perfectly with ourĀ 2.8mm/0.11" quick-connect wires, which press on firmly for a solid connection.
This is theĀ BurgundyĀ version -Ā we sell many more colours in the store. Each button comes with a split ring washer and nut to secure to your panel or enclosure.
Remember to useĀ resistorsĀ if using this as an input forĀ microcontrollerĀ or you'll be slathered in the magic blue smoke!
Specifications
- Max Dimensions: 18.06mm / 0.7" x 18mm / 0.7" x 29.4mm / 1.15"
- Shaft Dimensions: 14.89mm / 0.58" x 15.56mm / 0.6" x 18.7mm / 0.73"
- Button Height: 5mm
- Button Height Depressed: 3.5mm
- Weight: 4.6g
